Author: Abigail Dragich
KY Multiscale Core: EMC (University of Kentucky)
Tool Name: Helios FIB-SEM
Description: SEM image of an inner ear “hair cell” responsible for detecting sound within the cochlea. No one understands how these microstructures assemble and last over a lifetime of sound (since they cannot regenerate) making them highly researched in cell biology.
Author: Manisha De Alwis Goonatilleke
KY Multiscale Core: EMC (University of Kentucky)
Tool: FEI Talos F200X TEM
Description: The image shows an composite energy dispersive X-ray spectroscopy (EDS) elemental map of alumina (Al2O3) on a SiNx in situ heating chip. The circular region is a hole on the heating chip which contains a C overlay on which the sample is deposited.
Author: Dr. Chuang Qu
KY Multiscale Core: MNTC (University of Louisville)
Tool: SEM -Thermo Scientific Apreo
Description: This work presents the replication of shark skin dermal denticles using Glancing Angle Deposition (GLAD) atop line seeds. GLAD represents a highly advanced physical vapor deposition process that, when coupled with line seeds meticulously prepared through conventional photolithography, enables the creation of intricate three-dimensional micro/nanostructures on surfaces. These structures, in turn, impart exceptional properties, including superhydrophobicity, antifouling, and reduction in drag forces.The fabrication process was executed by Luca Caruso, a dedicated summer Research Experience for Undergraduates (REU) student, within the state-of-the-art cleanroom facilities at the University of Louisville.
Author: Dr. Chuang Qu
KY Multiscale Core: MNTC (University of Louisville)
Tool: SEM - Thermo Scientific Apreo
Description: This image offers a fascinating glimpse into the intricate world of a rose petal, as observed through a scanning electron microscope. Rose petals exhibit a unique property known as para-hydrophobicity. This means that while water droplets adhere to the surface, they do so with a notably high contact angle. This remarkable characteristic is a result of the petal's complex structure, featuring a combination of nanoscale stripes on microscale hemispheres. Interestingly, when the petal undergoes desiccation, the microscale hemispheres lose their plumpness. The petal's surface reveals a series of repetitive formations resembling Devils Towers. Devils Tower, a natural wonder located in Wyoming, rises over 5000 feet above sea level. It is distinguished by its surface with hexagonal columns. This geological marvel holds deep cultural significance as a symbol and object of reverence for Native American communities.
Author: Dr. Julia Aebersold & Prof. Gill Diamond
KY Multiscale Core: MNTC (University of Louisville)
Tool: TEM
Description: Conventional TEM Image of Candida Auris at 80 kV.
Author: Justin Gillham & Sophie Wegenast
KY Multiscale Core: AMIST (University of Louisville)
Tool: Form Cure
Description: An infinity mirror effect in the curing chamber used for post-curing 3D printed resin parts. Shown here is a field hockey mask for an injured UofL athlete in September 2022.
Author: Zhong Yang
KY Multiscale Core: MNTC (University of Louisville)
Tool: SEM - Thermo Scientific Apreo
Description: The microrobot is named as SerpenBot, it's MEMS device working in dry environment.
Author: Zhong Yang
KY Multiscale Core: MNTC (University of Louisville)
Tool: SEM - Thermo Scientific Apreo
Description: SerpenBot is MEMS microrobot, this is compare the size of the robot with flower pollen.
